Climate Check | Scenario Info

Climate Check | Scenario Info

For greenpass Climate Check one or more scenarios are needed.

​
​

Idea
Note: Scenarios can be e.g. the stock situation, different adaptation or retrofit scenarios or various design drafts!

Parameters

In total more than 30 parameters can be filled in the following 5 categories:


  • Building
  • Energy (Heating, Cooling and Electricity)
  • Open Space
  • Building Greenery (Green Roofs and Facades)
  • Trees

Building
The following building-related data can be entered.

Parameter

Definition

Entity

Footprint

Layout/ground plan area of all buildings

m2

Gross Floor Area

Gross Floor Area (GFA)

m2

Height Ø

Average height of all buildings

m

Number of Buildings

Total number of all buildings

pcs.

Type

Building Status of project:

  • Stock
  • New

Selection

Construction Year

Year of building completion of project

Year

Asset Class

Asset class of project:

  • Residential Building
  • Office Building
  • Retail Shop
  • Retail Shopping Center
  • Retail Warehouse
  • Hotel
  • Healthcare
  • Restaurants and Leisure
  • Industrial Warehouse
  • Industrial Warehouse Cooled

Selection

Asset Value

Asset value of project

€

Energy
The following energy-related data can be entered.

Parameter

Definition

Entity

Energy Source - Heating

Energy source of project for heating

  • Electricity (Grid Mix)
  • Gas
  • Wood Chips
  • Wood Pellets
  • District Heating
  • Oil
  • Others

Selection

Energy Demand  - Heating

Annual energy demand for heating (from EPC - energy performance certificate). Alternatively: Energy classes

kWh/a

Energy Price - Heating

Energy price of project for heating in €/kWh incl. VAT

€/kWh incl. VAT

Energy Source - Cooling

Energy source of project for cooling

  • District Cooling
  • Electricity (Grid Mix)
  • Others

Selection

Energy Demand  - Cooling

Annual energy demand for cooling (from EPC - energy performance certificate)

kWh/a

Energy Price - Cooling

Energy price of project for cooling

€/kWh incl. VAT

Energy Source - Electricity

Energy source of project for electricity:

  • Electricity (Grid Mix)
  • Others

Selection

Energy Demand  - Electricity

Annual energy demand for cooling (from EPC - energy performance certificate)

kWh/a

Energy Price - Electricity

Energy price of project for cooling

€/kWh incl. VAT

Photovoltaic

Performance of photovoltaic

kWp

Solar Heat

Performance of solar

kWh

Wind Power

Performance of generated wind power

kWh

Open Space
The following open space-related data can be entered.

Parameter

Definition

Entity

Sealed Surfaces

Sealed area of project (e.g. asphalt, concrete, ...)

m2

Semi-permeable Surfaces

Semi-permeable area of project (e.g. drainage plaster, ...)

m2

Green Space

Green area of project (e.g. lawn, meadow, shrubs, ...)

m2

Blue Space

Blue space of project (e.g. lake, creek, biotope, sprinklers, fountains, ...)

m2

Building Greenery

The following building greenery-related data can be entered.


Parameter

Definition

Entity

Green Roof - Extensive

Extensive (<15 cm substrate height) green roof area of project

m2

Green Roof - Semi-intensive

Semi-intensive (15-30 cm substrate height) green roof area of project

m2

Green Roof - Intensive

Intensive (>30 cm substrate height) green roof area of project

m2

Green Facade - ground-based

Area of grounded climbing plants (adult) on building within project

m2

Green Facade - planter-based

Area of plants in planters (adult) on building within project

m2

Green Facade - facade-based

Area of modular green wall and facade-greenery on building within project

m2


Trees

The following tree-related data can be entered.


Parameter

Definition

Entity

Tree - Small | 3m

Number of small trees with a height of <3m

Circumference: <18cm

pcs.

Tree - Medium | 6m

Number of moderate trees with a height of 6m

Circumference: 18-30cm

pcs.

Tree - Large | 10m

Number of large trees with a height of >10m

Circumference: >30cm

pcs.


IdeaNote: The more detailed the input - the more detailed the output
